Description
- Compact design matching various sensor sizes and resolutions
- Rich lineup including high NA models (microscope objective lens class)
- Available with or without built-in coaxial illumination
VS-TCM03-150
- Compact design matching various sensor sizes and resolutions
- Rich lineup including high NA models (microscope objective lens class)
- Available with or without built-in coaxial illumination
Additional information
| Aperture | F 7.5 |
|---|---|
| Filter thread | M46 P=0.75 |
| Lens mount | C-mount |
| Model | VS-TCM03-150 |
| Sensor size | 2/3" |
| Series | VS-TCM |
| Tv distortion | 0.03% |
| Wavelength | Visible |
| Weight | 225 g |
| Flange back | 17.526 mm |
| Dimension | (max.) Φ 48 x L = 119 mm |
| Optmag | 0.3x |
