VS-L8540/V

  • Line scan compatible 8K, 12K, 16K
  • V-mount type can adapt to various magnifications and mounts depending on the combination
  • Low distortion design focusing on peripheral performance
  • Reduced peripheral light fall-off and achieves high contrast
Category: Tag: Brand:

Description

  • Line scan compatible 8K, 12K, 16K
  • V-mount type can adapt to various magnifications and mounts depending on the combination
  • Low distortion design focusing on peripheral performance
  • Reduced peripheral light fall-off and achieves high contrast

Additional information

Aperture

F 4 ~ 16

Filter thread

M40.5 P=0.5

Focal length (mm)

85 mm

Lens mount

V-Mount

Model

VS-L8540/V

Sensor size

Φ 62 mm

Series

VS-L(V)

Tv distortion

0.00%

Wavelength

Visible

Weight

160 g

Operation

Manual (Lock screw M2)

Flange back

99.5 mm

Dimension

(max.) Φ 47.5 x L = 34 mm
