Description
- 1.1″ 12MP, 2.5μm compatible
- 4K resolution compatible lens
- f12mm/f16mm/f25mm/f50mm 4 types lineup
- Near-infrared correction minimizes focus shift from visible to IR range
VS-H1618-IRC/11
- 1.1″ 12MP, 2.5μm compatible
- 4K resolution compatible lens
- f12mm/f16mm/f25mm/f50mm 4 types lineup
- Near-infrared correction minimizes focus shift from visible to IR range
Additional information
| Angle of view | (Diagonal: 59.3°) 35.6° x 48.3° |
|---|---|
| Aperture | Close ~ F 1.8 |
| Filter thread | M40.5 P=0.5 |
| Focal length (mm) | 16 mm |
| Lens mount | C-mount |
| Model | VS-H1618-IRC/11 |
| Sensor size | 1.1" |
| Series | VS-H-IRC/11 |
| Tv distortion | -1.93% |
| Wavelength | Visible ~ 850mn |
| Weight | 290 g |
| Max aperture ratio | 1: 1.8 |
| Mod | 300 mm |
| Operation | Manual (Lock screw M2) |
| Flange back | 17.526 mm |
| Dimension | (max.) Φ45 x L = 92 mm |
