Description
- UV Coaxial Lighting
- Coaxial lighting equipped with 365nm UV LEDs.
- Ideal for fluorescence observation and detecting invisible resins/adhesives.
VCO-3325UV365
- UV Coaxial Lighting
- Coaxial lighting equipped with 365nm UV LEDs.
- Ideal for fluorescence observation and detecting invisible resins/adhesives.
Additional information
| Case_material | Aluminium alloy |
|---|---|
| Color | UV |
| Connector_assignment | SMR-03V-B (JST) / 1pin: V+, 2pin: NC, 3pin: V- |
| Cooling_method | Natural Air-Cooling |
| Current_consumption | 0.12 A |
| Environmental_declaration | RoHS Compliant |
| Height | 31.8 mm |
| Model | VCO-3325UV365 |
| Operating_environment | Temp 0 to 40 °C / Humidity 20~85% (with no condensation) |
| Operating_voltage | DC 24 V |
| Power_consumption | 3.3 W |
| Series | UV series (coaxial) |
| Storage_environment | Temp -20 to 60C °/ Humidity 20~85% (with no condensation) |
| Wavelength | 365 nm |
| Weight | 126 g |
| Long_side | 66 mm |
| Short_side | 43 mm |
| Window_long_side | 31 mm |
| Window_short_side | 22 mm |
| Max power consumption | 3.3 W |
