Description
- IR Coaxial Lighting
- Coaxial lighting equipped with 850nm Infrared (IR) LEDs.
- Effective for liquid penetration and transmission inspection.
VCO-10075IR850
- IR Coaxial Lighting
- Coaxial lighting equipped with 850nm Infrared (IR) LEDs.
- Effective for liquid penetration and transmission inspection.
Additional information
| Case_material | Aluminium alloy |
|---|---|
| Color | infrared |
| Cooling_method | Natural Air-Cooling |
| Environmental_declaration | RoHS Compliant |
| Height | 82 mm |
| Model | VCO-10075IR850 |
| Operating_voltage | DC 24 V |
| Power_consumption | 20.1 W |
| Series | IR series (coaxial) |
| Wavelength | 850 nm |
| Long_side | 126 mm |
| Short_side | 110 mm |
| Window_long_side | 98 mm |
| Window_short_side | 60 mm |
| Power consumption | 20.1 W |
