Description
- 10GigE frame grabber, the transmission rate can be up to 1000 Mbps/10000 Mbps.
- With 2 ports, the bandwidth of each port can be up to 10 Gbps.
- Supports IEEE 802.3 protocol.
- Conform to CE, UKCA, KC.
Dimensions
GT-6G20E
| Type | 10GigE Frame Grabber |
| Model | GT-6G20E |
| Number of Channels | 2 channels |
| Protocol | IEEE802.3 |
| Camera Compatibility | 10GigE industrial camera; GigE industrial camera |
| Number of Cameras | Max 2 cameras |
| Operating System | Windows 7/10/11 64bits, Linux |
| Power Supply | PCIe power supply |
| Power Consumption | 11W |
| Product Dimensions | 137.7mmx120.8mmx21.6mm |
| Net Weight | 122g |
| Heat Dissipation | Natural cooling |
| Host Bus Standard | PCIe Gen3 x4 |
| Host Bus Link speed | 8GT/s?PCIe 3.0? |
| Delivery bandwidth | 31.5 Gbps (Peak Bandwidth),20 Gbps (Sustained Bandwidth) |
| Interface | RJ45 x 2 |
| Transfer Rate | 1000 Mbps/10000 Mbps |
| Operating Temperature | 0??+60? |
| Storage Temperature | -20??+70? |
| Operating Humidity | 10%?95%RH,Non-condensing |
| Storage Humidity | 10%?95%RH,Non-condensing |
Additional information
| Interface | RJ45 x 2 |
|---|---|
| Operating humidity | 10%~95%RH,Non-condensing |
| Power consumption | 11W |
| Power supply | PCIe power supply |
| Product type | 10GigE Frame Grabber |
| Storage temperature | -20℃~+70℃ |
| Number of channels | 2 channels |
| Protocol | IEEE802.3 |
| Camera compatibility | 10GigE industrial camera; GigE industrial camera |
| Number of cameras | Max 2 cameras |
| Operating system | Windows 7/10/11 64bits, Linux |
| Heat dissipation | Natural cooling |
| Host bus standard | PCIe Gen3 x4 |
| Host bus link speed | 8GT/s（PCIe 3.0） |
| Delivery bandwidth | 31.5 Gbps (Peak Bandwidth),20 Gbps (Sustained Bandwidth) |
| Transfer rate | 1000 Mbps/10000 Mbps |
| Storage humidity | 10%~95%RH,Non-condensing |
