AX5F57CK250E

Sensor	GMAX3265
Image Sensor	29.9 mm x 22.4 mm CMOS
Shutter	Global
Resolution	9280 x 6992
Frame Rate	12.5 fps
Bit Depth	12
Mono/Color	Color
Pixel Size	3.2 ?m x 3.2 ?m
Pixel	65MP
S/N Ratio	40dB
Dynamic Range	66dB
Image Format	BayerGB8BayerGB10
ROI	Support
Y Flip	Support
Gain	1~32
White Balance	Support
Gamma	The range of 0 ~ 4,support LUT
Exposure Time	16?S~15S
Trigger Mode	Software Trigger/Hardware Trigger/Free Run Mode
SPC	Support
user Setting	Support two sets of user-defined configurations
Image Buffer	512MB data storage
Port	CameraLink
GPIO Interface	3x Opto-isolated input, 3x Opto-isolated output, 1x RS232
Lens Mount	M58 x 0.75
Power Supply	DC 24V power supply via 12 Hirose interface
Power Consumption	24V?6.83W
Product Dimensions	72mmx72mmx65mm(Not including rear case connector)
Net Weight	490 g
Storage Temperature	-30?~+80?
Operating Temperature	-30?~+50?

Description

A pantented flatness mediation scheme to eliminate area defocusing
Excellent heat dissipation design, precise temperature control and constant, temperature maintenance
Support Software Trigger/Hardware Trigger/Free Run Mode, support to use CameraLink acquisition card to trigger the camera
Support custom ROI, vertical mirror
With 10TAP outputs, the frame rate of up to 12.5fps at 85M clock for 65MP and 17.5fps at 85M clock for 50MP
Support automatic exposure, Gamma, LUT, and other ISP function
Color camera support automatic white balance?
Support for FFC function to provide more uniform picture quality
Support fan speed adaptive function for setting the target temperature of the sensor
Conform to CameraLink protocol and GenICam standard
Support DC 24V power supply
Comform to CE, KC, RoHS

Bit depth	12
Dynamic range	66dB
Exposure time	16us~15S
Frame rate	12.5 fps
Gain	1~32
Gamma	The range of 0 ~ 4,support LUT
Gpio interface	3x Opto-isolated input, 3x Opto-isolated output, 1x RS232
Image buffer	512MB data storage
Image format	BayerGB8BayerGB10
Image sensor	29.9 mm x 22.4 mm CMOS
Lens mount	M58 x 0.75
Pixel	65MP
Pixel size	3.2 um x 3.2 um
Port	CameraLink
Power consumption	24V≈6.83W
Power supply	DC 24V power supply via 12 Hirose interface
Resolution	9280 x 6992
Roi	Support
Sensor	GMAX3265
Shutter	Global
Spc	Support
Storage temperature	-30℃~+80℃
Trigger mode	Software Trigger/Hardware Trigger/Free Run Mode
User setting	Support two sets of user-defined configurations
White balance	Support
Y flip	Support
Mono-color	Color
S/n ratio	40dB
